Concise and fashionable product appearance
Economical and Environmental friendly product concepts
Easy installation and configuration
Support for fast ethernet – adaptive 10/100mbps network port, support POE power supply.
High Interoperability – Compatible with major platforms: 3CX, Broadsoft, Elastix, Asterisk, Xorcom, etc.
GENERIC
1 SIP Line
POE Enabled
Handset mode
Wall installation
Optional External Power Supply
CALL FEATURES
Call out / Answer
Call Hold / Resume
Call Transfer(Attended/Unattended)
Redial
Hot Line
Hot desking
PHONE FEATURES
Call logs with missed calls/ incoming calls/ outgoing calls. Max support 600 records(web)
Dial without registration
Action URL / Active URI
Web dial
AUDIO
Narrowband CODEC: G.711a/u, G.723.1, G.726-32K, G.729AB
Acoustic echo cancellation (AEC)
Dynamic Adaptive Jitter Buffer up to 300ms
DTMF: In-band, Out-of-Band – DTMF (RFC2833) / SIP INFO
NETWORKING
10/100Mbps Ethernet
IP Configuration: Static / DHCP / PPPoE
Network Access Control: 802.1x
VPN: L2TP / OpenVPN
VLAN
QoS
PHYSICAL SPECIFICATIONS
Keypad: 17 keys, including
-12 Standard Phone Digits keys
-5 Function keys
Handset (RJ11) x1
Standard RJ11 Handset Wire x1
RJ11 Port x1: Handset x1
RJ45 Port x1: Network x1
DC Power Input:: 12V / 0.5A
Power Consumption: Idle 1.6~2.3W, Peak 2.6~3.3W
Working Temperature: 0~40ȭ
Working Humidity: 10~95%
Installation: Wall installation
Color: Black
Device Dimensions: 96x222x59mm
Gift Box Dimensions: 302x105x67mm
Outer CTN Dimensions: 445x355x325mm (20 PCS)
